Electro Galvanized Wire-electro gi wire

0.25-5.0mm

Electro galvanized steel wire is made of high quality low carbon steel wire, through the process of drawing, annealing, acid washing and galvanizing. Boasting excellent corrosion resistance, it's crafted with precision. Strong yet flexible, it's perfect for fencing, crafting, and industrial applications.

Quantity

Contact Now

Electro galvanized Wire

Electro galvanized wire is made of high quality low carbon steel wire, through the process of drawing, annealing, acid washing and galvanizing. Galvanized wires with low and high carbon content obtained from different kinds of high quality wire rod. It has a bright surface and good corrosion resistance. The product of galvanized wire have uniformly tensile strength and zinc-coating, the wire diameter ranges from 0.25mm to 4.5mm. Galvanized wire is supplied in calibrated of selected weight.

electro galvanized wire

Materials: Q195,Q235,SAE1006,SAE1008, SAE1045

Applications: Weaving mesh, Construction,Fence, Agricultural and Industrial sectors.

Tensile Strength	350-550N/mm2, 600-800N/mm2
Zinc-coating	8-25grams/㎡
Elongation rate	20%-25%

Diameter(mm)	Coil size	Packing	Jumbo Coil max 800kg
Diameter(mm)	Coil size	Packing	ID(mm)	OD(mm)
0.25-0.45	8"	1-100kg
0.46-0.60	8",12"	1-100kg
0.61-1.60	12"14"16"	1-100kg	250-400	400-770
1.61-5.0			450	800
